Self-Normalizing Neural Networks

• Paper summary
• Self-Normalizing Neural Networks Klambauer et al. (2017)
• Günter Klambauer, Thomas Unterthiner, Andreas Mayr and Sepp Hochreiter

Abstract

• Success of Standard feed-forward neural networks(FNN) is rare
  • FNN cannot exploit many levels of abstract representations
• Self-normalizing neural networks
  • enable high-level abstract representations
  • Scaled exponential linear units (SELUs)
  • Banach fixed-point theorem
    • activations will converge toward zero mean and unit variance
    • vanishing and exploding gradients are impossible
    • Github link

Introduction

• Deep learning has very success
  • CNN: vision and video task
    • self-driving, AlphaGo
    • Kaggle: the “Diabetic Retinopathy” and the “Right Whale” challenge
  • RNN: speech and natural language processing
• Kaggle challenges that are not related to vision or sequential tasks
  • gradient boosting, random forests, SVMs are winning
  • very few cases where FNNs won, which are almost shallow
  • winning using FNN with at most 4 hidden layers
    • HIGGS challenge
    • Merck Molecular Activity challenge
    • Tox21 Data challenge
• Various normalization
  • Batch normalization Ioffe et al. (2016) ¹
  • Layer normalization Ba et al. (2016) ²
  • Weight normalization Salimans et al. (2016) ³
• Training with normalization techniques is perturbed by
  • SGD, stochastic regularization (like dropout), the estimation of the normalization parameters
• RNNs, CNNs can stabilize learning via weight sharing
• FNNs trained with normalization suffer from these perturbations and have high variance in the training error
  • This high variance hinders learning and slows it down
  • Authors believe this sensitivity to perturbations is the reason that FNNs are less successful than RNNs and CNNs

Figure 1. The training error (y-axis) on left: MNIST, right: CIFAR-10. FNN with bn exhibit high variance due to perturbations.

Self-Normalizing Neural Networks (SNNs)

Normalization and SNNs

• activation function: $f$
• weight matrix: $\bf{W}$
• activations in the lower layer: $\bf{x}$
• network inputs: $\mathbf{z} = \mathbf{W} \mathbf{x}$
• activations in the higher layer: $\mathbf{y} = f(\mathbf{z})$
• activations $\bf{x}, \bf{y}$ and inputs $\bf{z}$ are random variables

Assume

• all activations $x_{i}$
  • mean $\mu := \mathbb{E}(x_{i})$ across samples
    • $\mathbb{E} := \sum^{N}$: $N$ is a sample size (my notation)
  • variance $\nu := \textrm{Var}(x_{i})$
• That means
  • $\mu := \mathbb{E}(x_{1}) = \mathbb{E}(x_{2}) = \cdots = \mathbb{E}(x_{n})$
  • $\nu := \textrm{Var}(x_{1}) = \textrm{Var}(x_{2}) = \cdots = \textrm{Var}(x_{n})$
  • $\mathbf{x} = (x_{1}, x_{2}, \cdots, x_{n})$
• single activation $y = f(z), z = \mathbf{w}^{T} \mathbf{x}$
  • mean $\tilde{\mu} := \mathbb{E}(y)$
  • variance $\tilde{\nu} := \textrm{Var}(y)$

Define

• $n$ times the mean of the weight vector
  • $\omega := \sum_{i=1}^{n} w_{i}$, for $\mathbf{w} \in \mathbb{R}^{n}$
• $n$ times the second moment of the weight vector
  • $\tau := \sum_{i=1}^{n} w_{i}^{2}$, for $\mathbf{w} \in \mathbb{R}^{n}$

mapping $g$

$\left( \begin{array}{c} \mu \\ \nu \end{array} \right) \mapsto \left( \begin{array}{c} \tilde{\mu} \\ \tilde{\nu} \end{array} \right) \quad : \quad \left( \begin{array}{c} \tilde{\mu} \\ \tilde{\nu} \end{array} \right) = g \left( \begin{array}{c} \mu \\ \nu \end{array} \right)$

• mapping $g$ keeps $(\mu, \nu)$ and $(\tilde{\mu}, \tilde{\nu})$ close to predefined values, typically $(0, 1)$
  • like most normalization techniques: batch, layer, or weight normalization

Notation summary

• relate to activations: $(\mu, \nu, \tilde{\mu}, \tilde{\nu})$
• relate to weight : $(\omega, \tau)$

Definition 1 (Self-normalizing neural net)

A neural network is self-normalizing if it possesses a mapping $g : \Omega \mapsto \Omega$ for each activation $y$ that maps mean and variance from one layer to the next and has a stable and attracting fixed point depending on $(\omega, \tau)$ in $\Omega$. Furthermore, the mean and the variance remain in the domain $\Omega$, that is $g(\Omega) \subseteq \Omega$, where $\Omega = {(\mu, \nu) | \mu \in [\mu_{\textrm{min}}, \mu_{\textrm{max}}], \nu \in [\nu_{\textrm{min}}, \nu_{\textrm{max}}]}$. When iteratively applying the mapping $g$, each point within $\Omega$ converges to this fixed point.

• if both their mean and their variance across samples are within predefined intervals
  • then activations are normalized.

Constructing Self-normalizing Neural Networks

• Tow design choices
  1. the activation function
  2. the initialization of the weight

Scaled exponential linear units (SELUs)

$\textrm{selu}(x) = \lambda \left\{ \begin{array}{ll} x & \textrm{if} \ x > 0 \\ \alpha e^{x} - \alpha & \textrm{if} \ x \leq 0 \end{array} \right.$

1. negative and positive values for controlling the mean
2. saturation regions (derivatives approaching zero) to dampen the variance if it is too large in the lower layer
3. a slope larger than one to increase the variance if it is too small in the lower layer
4. a continuous curve.

Weight initialization

• propose $\omega = 0$ and $\tau = 1$ for all units in the higher layer

Deriving the Mean and Variance Mapping Function $g$

Assume

• $x_{i}$: independent from each other but share the same mean $\mu$ and variance $\nu$
  • $\mu := \mathbb{E}(x_{1}) = \mathbb{E}(x_{2}) = \cdots = \mathbb{E}(x_{n})$
  • $\nu := \textrm{Var}(x_{1}) = \textrm{Var}(x_{2}) = \cdots = \textrm{Var}(x_{n})$

some calculations

• $z = \mathbf{w}^{T} \mathbf{x} = \sum_{i=1}^{n} w_{i} x_{i}$
  • $\mathbb{E}(z) = \mathbb{E}( \sum_{i=1}^{n} w_{i} x_{i} ) = \sum_{i=1}^{n} w_{i} \mathbb{E}(x_{i}) = \mu \omega$
    • independent summation across dimension $(\sum^{n})$ and summation across samples $(\sum^{N})$
  • $\textrm{Var}(z) = \textrm{Var}( \sum_{i=1}^{n} w_{i} x_{i} ) = \nu \tau$
  • used the independence of the $x_{i}$
• Central limit theorem (CLT)
  • input $z$ is a weighted sum of i.i.d. variables $x_{i}$
  • $z$ approaches a normal distribution
  • $z \sim \mathcal{N} (\mu \omega, \sqrt{\nu \tau})$ with density $p_{N}(z; \mu \omega, \sqrt{\nu \tau})$

mapping $g$

calculation of $g$

Remind SELUs

$\textrm{selu}(x) = \lambda \left\{ \begin{array}{ll} x & \textrm{if} \ x > 0 \\ \alpha e^{x} - \alpha & \textrm{if} \ x \leq 0 \end{array} \right.$

integration

analytic form $\mu$ and $\nu$

error function

complementary error function

Stable and Attracting Fixed Point $(0, 1)$ for Normalized Weights

Assume

• $\mathbf{w}$ with $\omega = 0$ and $\tau = 1$
• choose a fixed point $(\mu, \nu) = (0, 1)$
  • $\mu = \tilde{\mu} = 0$ and $\nu = \tilde{\nu} = 1$

Jacobian of $g$

useful calculations

• $\mu = \tilde{\mu} = 0$ and $\nu = \tilde{\nu} = 1$
• $\omega = 0$ and $\tau = 1$
• $\textrm{erf}(0) = 0$ and $\textrm{erfc}(0) = 1$
• $\frac{\textrm{d}}{\textrm{d} x} \textrm{erf}(x) = \frac{2}{\sqrt{\pi}} e^{-x^{2}}$
  • $\left. \frac{\textrm{d}}{\textrm{d} x} \textrm{erf}(x) \right|_{x=0} = \frac{2}{\sqrt{\pi}}$
• $\frac{\textrm{d}}{\textrm{d} x} \textrm{erfc}(x) = \frac{\textrm{d}}{\textrm{d} x} (1 - \textrm{erf}(x)) = - \frac{\textrm{d}}{\textrm{d} x} \textrm{erf}(x)$
  • $\left. \frac{\textrm{d}}{\textrm{d} x} \textrm{erfc}(x) \right|_{x=0} = -\frac{2}{\sqrt{\pi}}$

insert $\mu = \tilde{\mu} = 0$, $\nu = \tilde{\nu} = 1$, $\omega = 0$ and $\tau = 1$ into Eq. (4) and (5)

python code

In [1]: from scipy.special import erfc
In [2]: import math
In [3]: alpha = -math.sqrt(2/math.pi) / (math.exp(0.5) * erfc(1/math.sqrt(2)) - 1)
In [4]: l = math.sqrt(2) / math.sqrt(1 + alpha**2 * (-2 * math.exp(0.5) * erfc(1/math.sqrt(2)) + math.exp(2) * erfc(2/math.sqrt(2)) + 1))
In [5]: alpha
Out[5]: 1.6732632423543778
In [6]: l
Out[6]: 1.0507009873554805

calculation of $\frac{\partial \tilde{\mu}}{\partial \mu}$

blackboard

calculation of $\frac{\partial \tilde{\mu}}{\partial \nu}$

blackboard

To be continued

아직 정리가 덜 됐습니다. 조만간 정리해서 올리도록 하겠습니다.
